i3 Continuous Inkjet Printer
More cost-efficient and stable coding technology.
iCODE printing technologies provide a cost-effective and lower total cost solution compared to similar industrial inkjet printers on the market, saving the cost in the long term. Our heritage in industrial coding and marking equipment means compliance and peace of mind.
Print Capabilities
CIJ (Continuous Inkjet) printers excel at high-speed, contact-free printing on diverse surfaces like metal, plastic, glass, paper, and wood, including curved and textured materials. Their primary capabilities include printing text, barcodes, expiration dates, lot codes, and simple logos onto products for coding and marking.
The iCODE CIJ printer allows to edit and create the fonts or special logo on the system directly, support message transfer by USB, Ethernet, and RS485 to the printer.
Product Feature
10.1 inches Touchscreen
i3 equiped with a 10.1 inches touchscreen allows operators to quickly and easily set up and control the printing process
User-friendly Interface
A user-friendly interface with mistake-proof function operation and editing, reduce the risk of errors or delays caused by complicated settings or confusing menus.
Flexibel Printhead
The parts of the printhead can be replaced separately lower the cost and save service time. The printhead comes with auto-flush function when stopping the pirnter. Easy to use, lower down-time.
Modular Design
By separating different compartments and parts, the i3 CIJ printer allows you to replace the ink and solvent cartridges with ease, on the other hand, the modular structure provides convenience to the engineer to do the maintenance, inspection, and repair.
Max print capability
Dotmatrix up to 34 dots, print lines up to 5 lines.
Full Automation Technology
Auto-flushing, auto-modulation, automatic viscosity and pressure controls.
Print Flexibility
360° printing direction, equiped with RS232, USB, Ethenet, sensor and encoder.
Always brand-new
Teflon coating of the printer cabinet for easy wiping off any ink and dirt.
Outstanding Cooling System
Large-area cooling backplane and built-in fan efficiently cool down the printer for any harsh working environment.
Meticulously engineered and qualified by the most modern methods
the iCODE’s i3 CIJ printer latest enhancements bring you:
- Technology leaps grounded in time-tested industrial processes for maximized uptime.
The printer comes with auto flush function, ensuring smooth start-up everytime. - Cutting-edge design with simplified UI and modular components for easy operation, maintenance or repair, reduce the learning
cost, master the operation with ease. - Clear, customizable, traceable codes – that meet customers’ growing demand for supply chain visibility, a full range of inks meet the requirement of various materials marking needs.
Continuous Inkjet Printer Specification:
| i3 – Continuous Inkjet Printer Specification |
||||
| Model | i3 | i3Mi | i3HS | i3Pi |
| Print Capability |
(7×5 dotmatrix) 1-4 Lines (5×5 dotmatrix) 1-5 Lines |
(7×5 dotmatrix) 1-4 Lines (5×5 dotmatrix) 1-5 Lines |
(7×5 dotmatrix) 1-4 Lines (5×5 dotmatrix) 1-5 Lines |
(7×5 dotmatrix) 1-4 Lines (5×5 dotmatrix) 1-5 Lines |
| Max Speed | 344m/min | 430m/min | 430m/min | 344m/min |
| Printhead |
Conduit Length: 3m Nozzle Size: 60μm |
Conduit Length: 3m Nozzle Size: 40μm |
Conduit Length: 3m Nozzle Size: 50μm |
Conduit Length: 3m Nozzle Size: 60μm |
| Font Matrix | 1 Line: 5×4; 5×5; 7×4; 9×6; 12×8; 16×11; 19×14; 24×17; 32×22 | |||
| Character Height Range | Font height: 1-15mm | |||
| Printing Distance Range | 2mm-30mm (10mm is recommended) | |||
| Screen Size | 10.1 inches | |||
| Print Content |
English, Simplified Chinese, Arabic Numerals, Serial Number, Barcode, Shift, DM/QR, UPC A&E, EAN8&13, Code 128A, B&C, Code special logos and characters) |
|||
| Memory Storage | Up to 1000 messages (additional storage can be extended by USB) | |||
| Connection | USB, RS485, Ethernet, Product sensor, Alarm Light, Alarm Relay, Encoder | |||
| Industrial Protection | IP55 | |||
| System Language | Simplified Chinese, Traditional Chinese, English, Korean, Russian, Polish, Persian, Arabic, Spanish, German, Indonesian, Vietnamese, Croatian, Thai, Slovenian, Slovak, Bosnian, Portuguese, Italian, etc., Support customizing language. |
|||
| Catridge Volume | 500ml – Ink Cartridge 750ml – Make-up Catridge |
|||
| Temperature/Humidity Range | Ambient Temperature: 0 – 50°C (32 – 113°F) Ambient Humidity: 0 – 95% relative humidity (non-condensing) |
|||
| Power | AC-100-240V, 50/60Hz, 80VA | |||
| Printing Direction | 360° All-direction Printing | |||
